Indoor Small Pixel Pitch
HD Resolution Light weight Dual system Common Cathode Energy-Saving
Creative splicing Front Maintenance Fast installation Wide Viewing-angle
Dimension
weight 4.5Kg
Common Cathode Energy-Saving
Common cathode technology, green and energy-saving.
No soldering, high luminous efficiency, reduces failure rate of LED lamps.
Smaller chip size, higher contrast ratio.
Front maintenance
Can be applied to different
installation environments
Dual card dual electric
Configurable dual backup version to ensure uninterrupted power supply.
Signal not lost, more stable and reliable.
Seamless Splicing
Die-casting Alumium Cabinet sctructure with CNC high-precision processing
(Flatness of Cabinet≤0.1mm)
Screwless design for faster and more secure installation
Super silent fanless design
Creative splicing
Supports shapes such as right angles and arcs to meet various creative splicing needs.
Installation method
Support multiple installation methods such as lifting, wall mounted installation, and embedded installation, suitable for more scenarios.
High brightness and high gray
High grayscale & high refresh rate, no scan lines in photography, realistic and delicate images with vivid, saturated colors.
Cabinets seamless splicing to make 2K, 4K, 8 and 16 K ultra high definition LED screen
Applications
Specifications
| Pixel Pitch | P0.9375 | P1.25 | P1.56 | P1.875 |
| LED Type | MIP0202 | MIP0606 | MIP0606 | MIP1010 |
| Physical density(Dot/sqm) | 1137778 | 640000 | 409600 | 284444 |
| Module resolution | 160X180 | 120X270 | 960X216 | 80X180 |
| Module size(mm) | 150X168.75 | 150X337.5 | 150X337.5 | 150X337.5 |
| Panel Dimension (WXHXD/mm) | 600X337.5X27.5 | 600X337.5X27.5 | 600X337.5X27.5 | 600X337.5X27.5 |
| Panel Resolution | 640X360 | 480X270 | 384X216 | 320X180 |
| Module QTY(WXH) | 4X2 | 4X1 | 4X1 | 4X1 |
| Panel weight(kg) | 4.5 | 4.5 | 4.5 | 4.5 |
| Maintenance Mode | Front maintenance | Front maintenance | Front maintenance | Front maintenance |
| Cabinet Material | Die-cast aluminum | Die-cast aluminum | Die-cast aluminum | Die-cast aluminum |
| Brightness Carlibration | Have | Have | Have | Have |
| Brightness(Nits) | 600-800 | 1200/2000/3500 | 1200/2000/3500 | 1200 |
| Color temperature(K) | 8000-12000 Optional | 8000-12000 Optional | 8000-12000 Optional | 8000-12000 Optional |
| Viewing angle(V/H) | 170°/170° | 170°/170° | 170°/170° | 170°/170° |
| Brightness/Color uniformity | ≥99.8% | ≥99.8% | ≥99.8% | ≥99.8% |
| Contrast ratio | 15000 : 1 | 15000 : 1 | 15000 : 1 | 15000 : 1 |
| Frame rate | 50/60 | 50/60 | 50/60 | 50/60 |
| Drive mode | 1/45 scan | 1/27 scan,1/45 scan | 1/12scan,01/48 scan | 1/45 scan |
| Grey level | 14-16bit(Optional) | 14-16bit(Optional) | 14-16bit(Optional) | 14-16bit(Optional) |
| Refresh rate(Hz) | 3840/7680 | 3840/7680 | 3840/7680 | 3840/7680 |
| Max. power consumption(W/sqm) | 350 | 350 | 350 | 350 |
| Avg. power consumption(W/sqm) | 100 | 100 | 100 | 100 |
| Protection grade | IP31 | IP31 | IP31 | IP31 |
| Input Power | AC90-264V,47-63Hz | |||
| Wroking temperature/humidity(℃/RH) | -20~60℃/10%~85% | |||
| Storage temperature/humidity(℃/RH) | -20~60℃/10%~85% | |||
| Certificatiom | CCC/CE/RoHS/FCC/CB/TUV/IEC | |||
